Tornatech JPLT Jockey Pump Controller

Model: JPLT

The Tornatech JPLT Jockey Pump Controller uses a Type-F fuseless full voltage across-the-line starter with a ViZiLT operator interface to maintain system pressure in fire pump serviced systems.

Email Inquiry Call Us

Specifications

Voltage (VAC)	110-600
Frequency (Hz)	50/60 Hz
Listing / Approval	UL Listed
Enclosure Rating	NEMA 2 (Drip-proof)
Brand Model Series	Tornatech JPLT
Starting Method	Across-the-Line (Full Voltage)
Phase	1 or 3

Product Description

Benefits/Features
• ViZiLT operator interface with H-O-A position, cut-in/cut-out pressure, and motor overload indication on the door front
• Type-F fuseless magnetic motor starter for simple, low-cost across-the-line full voltage starting
• Main disconnect handle with HAND-OFF-AUTO pushbuttons and menu navigation keypad
• Minimum run period and sequential start timers, plus a non-resettable elapsed time meter and pump start counter
• Audible alarm and pressure transducer standard
• Short circuit current ratings up to 65kA depending on voltage and horsepower
• NEMA 2 enclosure standard
• Available from 110 to 600 V, single or three phase, covering 1/4 to 25 HP
